Suitable for High load applications |
− |
Suitable for Vertical shaft applications |
Ο |
Suitable for applications with Oscilating movements |
Ο |
Suitable for applications with Severe vibrations |
+ |
Suitable for applications that require Rust protection |
+ |
Suitable for applications that require Water resistance |
+ |
Suitable for applications that require Frequent start-up |
Ο |
Speed (max.) n x dm (x 1000) |
300 |
Çalıştırma sıcaklığı aralığı |
-30 – 120 °C |
Dropping point (min) ISO 2176 |
180 °C |
Penetration DIN ISO 2137, Worked, 60 strokes (10⁻¹mm) |
265 - 295 |
Penetration DIN ISO 2137, Prolonged (max.), 100 000 strokes, 10⁻¹mm |
+50 |
Mechanical stability - Roll stability, ASTM D1831 (max.) 50 hrs at 80°C, 10⁻¹mm |
+50 |
Mechanical stability, V2F test, 144 hrs |
M |
Corrosion protection, Emcor, ISO 11007, Distilled water |
0-0 |
Corrosion protection, Emcor, ISO 11007 modified, Water washout |
0-0 |
Corrosion protection, Emcor, ISO 11007 modified, 0.5% NaCl |
- |
Water resistance (max.) DIN 51807/1, 3 hrs at 90 °C |
1 |
Oil separation DIN 51817, 40°C, % |
1-6 |
Lubrication ability, R2F test B at 120°C |
Başarılı |
Copper corrosion (max.) DIN 51811 /ASTM D4048, 24 hrs at 100°C |
2 max.at 110°C |
Rolling bearing grease life (max.) ROF test, L50 life, 10000 r/min, hrs at °C |
1000 at 100°C |
Low temperature torque, Start/Running, mNm |
300/100 at -30°C |
